Commercial High Speed Doors

Energy-efficient, fast-acting, and wind-resistant commercial traffic doors.

Industrial High Speed Roll-Up Doors

Fabric or rubber doors for interior or exterior use. Great for a variety of applications, including industrial, medical and cold storage.

Do you need maximum environmental controls and a fast durable door that can withstand impact? If you are looking for a local specialist our company offers sales, service and installation of the most durable high-speed doors on the market.

Your new commercial high speed door can stand up to all types of abuse and weather. Our doors are durably made by the best manufacturers in the industry including Raynor, TNR and Hormaan.

You’ll be able to choose from a complete range of top-quality commercial high speed doors at the best value for your business.

Raynor RapidCoil Commercial High Speed Fabric Doors

Raynor’s line of RapidCoil fabric, high speed doors utilize the industries best sealing technology, which gives an extremely tight seal against wind, rain and contaminants. RapidCoil doors, depending on size, can open as fast as 8 feet per second in some applications. By combining a tight sealing door with high speed operation, a more energy efficient environment is created, which can decrease operating costs in manufacturing environments. The RapidCoil line also features a soft bottom edge, photo eyes and reversing edge across all models, adding an uncompromising safety factor into the entire line. RapidCoil high speed fabric doors are available in a variety of colors with multiple vision options and activation methods

RapidCoil RC100

Raynor RapidCoil RC200

RapidCoil RC300

Raynor RapidCoil RC300HD

Raynor FabriCoil Traffic Doors

With many of the desired features of typical commercial high-speed doors, Raynor FabriCoil traffic doors offer excellent durability and reliability at an affordable price. Our tough vinyl curtain is designed for interior applications, ideal for high traffic areas.

TNR Doors - High Speed Rubber Doors

TNR offers a variety of doors for the following industries: Food & Beverage, Mining & Industrial, Parking & Automotive, and Logistics & Transportation. They have over 50 years of combined engineering experience that we will put to work for you.

These doors have revolutionized the door industry by providing a more reliable, more durable, longer lasting performance with greater impact ability. TNR doors will substantially reduce your long term cost of ownership and provide you with the lowest life cycle cost available. Depending on the application the typical return on investment of a TNR door is between 12-36 months, when considering the following criteria:

HDF Door

Model HDP - Low Headroom Parking Door

Springless Low Headroom rubber roll-up door
Tight overhead spaces with clearance limited to a minimum of 18"
Applications for condominiums, office complexes, hotels, public parking and airports
Double angle steel knock-away bottom bar designed to take full impacts with little or no downtime and is easily reset from the floor without the use of special tools or parts.
Includes a high efficiency helical gear head operator with a multi-function capacity programmable logic controller
Door speeds up to 30" per second

Which Model is Best for my Industry?

FOOD & BEVERAGE DOOR MODELS

MINING & INDUSTRIAL DOOR MODELS

HDM - Manual Rubber Door
HDE - Economy Rubber Door
HDL - Large Rubber Door
HDL-DD - Large Rubber Direct Drive Door
HDXL - Extra Large Rubber Door
HDC-DD - High Cycle Rubber Direct Drive Door

PARKING & AUTOMOTIVE DOOR MODELS

LOGISTICS & TRANSPORTATION DOOR MODELS

HDD - Heavy Duty Rubber Dock Door
HDS - High Speed Rubber Door
HDT - High Traffic Rubber Door
HDC - High Cycle Rubber Door
HDFX - High Speed Exterior Door
CHILLFAST - High Speed Freezer Door

Model HDLH - Extra Low Headroom Parking Door

Model HDM - Manual Rubber Door

Applications for Manufacturing Process and Maintenance Buildings in: mining, petroleum, military, agriculture, pulp & paper, and steel
Suitable for applications up to 15 feet in width or height
Self-supporting steel mounting angle
Knock-away double angle steel bottom bar for 10lb/ft with rubber loop
Manual chain hoist
Counterbalance spring assembly cycle rating of 50,000

Model HDE - Economy Rubber Door

Applications for the Manufacturing Process and Maintenance Buildings in: mining, petroleum, military, agriculture, pulp & paper, and steel.
Suitable for applications up to 20 feet in width or height
Self-supporting steel mounting angle
Knock-away double angle steel bottom bar for 10lb/ft with rubber loop
Frame mounted thru-beam photoelectric sensor
Heavy duty gear operator with push button controls open, close, stop
Door speed of up to 18 inches per second
Counterbalance spring assembly cycle rating of 100,000

Model HDC-DD / HDL-DD High Cycle Rubber Doors

Applications in Manufacturing, mining, food processing, automotive, bus transit stations, parking garages, postal, airports, and railways.
High cycle springless operation with Variable Frequency Drive
Suitable for applications up to 25 feet wide and 20 feet high
Self-supporting steel mounting angle
Knock-away double angle steel bottom bar with rubber loop and reversing edge
Thru-beam photoelectric sensor
Heavy-duty gear head direct drive operator (no sprockets or chains required)
Multi-function capacity PLC with inverter drive for soft start soft stop operation
Door speeds of up to 63” per second to open; up to 30” per second to close (depending on door size)
https://www.youtube.com/watch?v=liSQnhlAgrE#action=share

Model HDL Large Size Rubber Door

Applications in heavy manufacturing, steel, pulp & paper, waste management, oil & gas, and mining.
Suitable for applications up to 30 feet wide and 30 feet high
Self-supporting steel mounting angle
Knock-away double angle steel bottom bar for 10lb/ft with rubber loop and reversing edge
Frame mounted thru-beam photoelectric sensor
High-Efficiency Heligear Head (HG) Operator with multi-function PLC panel
Door speed of up to 20 inches per second
Counterbalance spring assembly cycle rating of 50,000

Model HDXL - Extra large Size Rubber Doors

Applications in heavy manufacturing, steel, pulp & paper, waste management, oil & gas, and mining.
Suitable for applications up to 55 feet wide and 35 feet high
Self-supporting channel steel C10 & flat bar mounting assembly
Knock-away double angle steel bottom bar for 15lb/ft with rubber loop and reversing edge
Frame mounted thru-beam photoelectric sensor
High-Efficiency Heligear Head (HG) Operator with multi-function PLC panel
Door speed of up to 12 inches per second
Counterbalance spring assembly cycle rating of 50,000

Model HDF - High Speed Fabric Door

Application - Food & Beverage Industries
Polyester Woven Material. Flexible and resistant to abusive environments and impacts
Suitable for applications up to 16 feet wide and 14 feet high
Heavy duty construction designed for ease of installation and performance stability
Impactable: Bottom bar is designed to release upon impact with auto reset.
Eliminates downtime
Sleek profile with easy installation, reduced clearance and minimal maintenance
No hinges, cables, pulleys or counterbalance springs
High-speed operation conserves energy and reduces climate fluctuations
Airwave reversing edge and thru-beam photo eyes Optional full-width window panels provide excellent visibility
Full perimeter weather seal to minimize air infiltration
Standard panel ribs provide resistance to positive and negative air pressure
https://youtu.be/IyF5ZPyIfqg

Model CHILLFAST - High Speed Freezer Door

Application Provides energy and operational savings for food and beverage processing, cold storage and distribution.
High speed roll-up door reduces cooling energy costs
Variable Frequency Drive system provides Soft Start / Soft Stop
Insulated reinforced vinyl curtain endures cold temperatures
Soft bottom with safety edge, releases upon impact & auto resets
Retention guides improves curtain stability & durability
Aluminum guides with integrated photo-eyes, wear strips and fabric loop seals
Standard aluminum roll cover & optional operator hood with white finish
GFCI protected heater cable system in guides, bottom edge and hoods
Standard plug and play cable system
Optional air curtain system, heated or non-heated
Suitable for applications up to 13' wide and 18'6" high

Model HSR-007 - High Speed Aluminum Security Grille

High Security insulated door system with springless operation
Up to 54 inches per second opening speed
Suitable for applications up to 19 feet wide and 19 feet high
Anodized aluminum exterior, foil-coated aluminum interior
Insulated rigid polyurethane foam core slat
Complete perimeter seals are included with each door
Frame-mounted thru-beam photoelectric sensor
Direct Drive System complete with Safedrive® integrated safety brake
Soft Start - Soft Stop using Variable Frequency Drive technology
HSR-007B insulated slat for applications up to 19’ x 19’
HSR-007A perforated slat for applications up to 19’ x 19’ or 22’ x 10’ high

Model HDFX High Speed Exterior Door

Application - Light manufacturing, food processing, automotive, transit & postal depots, and airports. Also a cost effective alternative for interior doors that are larger than 16’ x 16’
TNR delivers a hybrid door system that combines the cost and speed benefits of fabric doors with the rugged durability of the traditional TNR door
3/32″ SBR black rubber, polyester core weave
Simple end plate & mounting angle design, sleek profile with easy installation, reduced clearances & minimal maintenance
Self-supporting steel frame
No hinges, cables, pulleys or tension springs
Withstands an impact and is easily reset
Knock away bottom bar with rubber loop and wireless reversing edge
Guide mounted thru-beam photoelectric sensor
Warranty – Five years on curtain and NEWGEN Guide and Curtain Lok – Five years or 1,000,000 cycles on drive/operator – Two years on all other components
Options – Hoods, traveling wind-bar, guide guards, windows

Model HDD - Heavy Duty Dock Door

Application - Ideal for distribution, commercial, and manufacturing applications
Reliable and consistent door operation and impact release performance; no guide gap maintenance required
Suitable for applications up to 10 feet wide and 12 feet high
In-board spring assembly with 25,000 cycle rating
Sleek profile with easy installation, reduced clearances, and minimal maintenance
Manual Chain Hoist, 4.5:1 – fast and easy operation

Hörmann High Performance Doors

Hörmann High Performance Doors manufactures a variety of rigid and fabric, high speed door models which provide a solution to any new or retrofit project. Designed with simplicity and energy-efficiency in mind, these high speed doors are in operation worldwide in a variety of applications including: industry, parking, commercial, warehousing, food and beverage processing, retail automotive, manufacturing, cold storage, mining, and many others.

Speed-Commander™ 1400 SEL Fabric Panels

Speed-Commander™ 1400 SEL Food-Master

Speed-Commander™ 1400 SEL Clean-Master

Speed-Commander™ 1400 SEL Cool-Master

Speed-Master® 1600 L Eco

Speed-Master® 1600 L

Speed-Master® 1600 XL

Interior/Exterior High Speed Door for Large Openings
Versatile Fabric Door Model
Sectional Panel with Optional Windlocks
Low-Profile Guide Tracks and Built-In Light Grid
Smart Start™ NXT NEMA 4X Standard

Speed-Master® 2600 L

Speed-Master® 4600 L

Speed-Guardian™ 5000 (New in 2017)

Interior/Exterior Insulated Rigid Door
The Speed-Guardian™ 5000 Series of high performance rigid panel doors (replaces the Speed-Guardian™ 4000 Series)
More efficient slat design (new overall slat dimensions are 10" high x 1-5/8" thick with improved thermal breaks in the solid slats)
NEMA 4X Smart Start™ NXT control box as standard
Optional tinted vision slats for privacy

Speed-Guardian™ 5000 LP 42

Interior/Exterior Insulated Rigid Door - Low Profile Guide Tracks
Lower Price
1-5/8" insulated panel and double-pane windows with Duratec® protective coating
Operating speeds of 8" per second, allowing building owners to realize a savings for door openings where low cycles will exist
Jackshaft motor is used with the optional high lift and vertical lift track configurations

Which door model is best for my industry?

FOOD & BEVERAGE

MINING & INDUSTRIAL

PARKING & AUTOMOTIVE

LOGISTICS & TRANSPORTATION

HDD - Heavy Duty Rubber Dock Door
HDS - High Speed Rubber Door
HDT - High Traffic Rubber Door
HDC - High Cycle Rubber Door
HDFX - High Speed Exterior Door
CHILLFAST - High Speed Freezer Door
